Stainless steel gear pump
Model :
HCS series
- Well water extraction
- Water Tower
- Catering industry
- Water spray cooling device
- Automatic water supply for buildings
- Spring water
- Use water equipment
- This model has special water flow design and excellent liquid transportation.
- The motor is equipped with a protective device to prevent the motor from burning.
- Suction lift:Max.6m
- Ambient temperature: MAX.+40°C
- Liquid temperature: +4°C~+80°C
- Applicable liquid: clean water; or non-corrosive, solid-particle-free liquid with properties close to water
| TYPE | POWER | BORE | PHASE | MAX CAPACITY | MAX HEAD | WEIGHT | CURVE CODE |
|---|---|---|---|---|---|---|---|
| HP(KW) | Inch(mm) | ∅ | L/min | M | KG | ||
| HCS220-1.37 2S | ½(0.37) | ¾”(20) | 1 | 56 | 35 | 9.5 | A |
| HCS225-1.37 2S | ½(0.37) | 1”(25) | 1 | 56 | 35 | 9.5 | A |
| HCS225-1.75 2S | 1 (0.75) | 1”(25) | 1 | 66 | 48 | 17.5 | B |
| TYPE | POWER | BORE | PHASE | MAX CAPACITY | MAX HEAD | WEIGHT | CURVE CODE |
|---|---|---|---|---|---|---|---|
| HP(KW) | Inch(mm) | ∅ | L/min | M | KG | ||
| HCS225-1.37 265 | ½(0.37) | 1”(25) | 1 | 45 | 36 | 9.5 | B |
| HCS225-1.75 265 | 1(0.75) | 1”(25) | 1 | 54 | 41 | 15.5 | C |
